HOOK UP - ALL CONTROLLERS IN THIS RANGE
               The Controller is for use on positive regulated tracks only. Verify the polarity of the track prior to use, do not attempt to connect the controller to  negatively regulated or Drag  tracks.

All power leads must be connected to the correct coloured terminals, Failure to do so may cause tripping of any of a number of re-settable fuses and reduce the life of the Controller.

When connecting the power leads, Always connect the Red power lead First! The Red lead must remain connected at all times. In the event the lead is not hooked up, the Controller will supply full power and the car will take off.

FEATURES

·         “Electronic” high gain/high Output Drive circuit.
·         “Transistorized Braking” (specifically designed for wide
          (usable)  Braking range for HO and 1/32 cars)
·          “Mistake Proof” reverse polarity protection, No fuses to
          replace.
·         Excellent Throttle Response optimized for all HO and 1/32
          cars and driving types.
·         “Continuously variable throttle control” (no steps) 150 bands).
·         Smooth Trigger Action with “ No Deadband”  between
          Brake/Coast to Throttle (reduces Track times).
·         Light weight Handle with easy to use controls located at the
          top and sides.
·         Infinitely adjustable Brake and Sensitivity controls (0-Max).
·         Coast/ Brake  Switch uses Same Control Knob for
          Brake/Coast (Professional model)
·         Wide Sensitivity Adjustment Range
·         High intensity Blue (eye piercing) Power LED Indicator and
          Illuminated 3rd Eye Logo located in the handle.
·         4ft. long flexible Power Leads allows easy of use at all
          Tracks.
·         Built-in “Clicker” - (Blast Relay) for Absolute maximum power
          to the motor at full throttle (Professional model only).
·         Fully Electronic Choke with Choke On/Off Switch and
          Bypass Button (Professional model only).
·         Ample Heat Sinking allows for maximum cooling
·         Attractive Professional looking Styling with Kelly Handle and
          Trigger (used exclusively).
·         22nd Century- Fully Electronic high technology linear design.
·         Track proven by FASTER lap times.

OPERATION - “VersaTrollers”, HO-1/32 - Expert and Professional Models

When the track power is on and the unit hooked up correctly, the Blue U.B. LED will be illuminated.

The blue knob is the Sensitivity adjustment (all Models). Turn the knob counter-clockwise for less sensitivity, and clockwise for greater sensitivity.

The red knob is the Brake adjustment (Maverick model only). Turn the knob counter-clockwise for no braking and clockwise for maximum brake. Note: the Brake adjusts from No Brakes to Maximum.

The Green knob is the Coast/Brake adjustment (Expert and Professional models). When the Coast/Brake Switch is in the Brake position: Turn the knob counter-clockwise for minimum brake and clockwise for maximum brake. When the Coast/Brake switch is in the Coast position: Turn the knob counter-clockwise for minimum Coast speed and clockwise for maximum Coast speed.

The Coast/Brake Switch in the back position, the Coast/Brake knob serves as the Brake Control function. The Coast/Brake Switch is in the forward position, the Coast/Brake knob serves as the Coast control.

The Yellow knob is the Choke adjustment (professional model only). When the Choke On/Off FTB Switch is in the on or FTB) position: Turn the knob counter-clockwise for Minimum Choke and clockwise for Maximum Choke. The choke adjustment can remain set to the desired leavel.

The Choke On/Off Switch in the back position turns the Choke Off. When the switch is in the center (on) or forward (FTB) position turns the Choke on.

The Choke On/Off Switch in the forward position the Choke is on and bypasses the choke when the trigger is at full throttle (FTB = Full throttle bypass).

When the Choke Bypass Button, is pressed any time the choke is on, bypasses the choke function.

PRICES;-

Maverick HO -1/32 - Adjsutable Brake & Sensitivity, Power cables to handle  £125.00

Expert HO - 1/32 - Adjustable Brake, Sensitivity, Clicker (blast relay), High power drive heat sink £149.20

Pro HO - 1/32 - Adjustable Brake, Sensitivity, Clicker (blast relay) Hi power drive heat sink and electronic choke £235.00
